Description

• Reputed internationally known single and twin-screw compressors with efficient automated oil management system for optimum oil separation
• Reliable, Energy efficient, Highest full and part load energy efficiencies, through single and multiple refrigeration circuits, electronic expansion valves
• Stepless variable speed capacity control for precise temperature control
• Water cooled condenser shell & tube type with Seamless tubes
  • With Finned Carbon steel, SS 304/SS 316 (Optional on request)
  • With Highly efficient high heat transfer tubes in copper (for refrigerant other than Ammonia) for low refrigerant charge.
  • With SS 304 / SS 316 (Optional on request)
  • Higher Fouling factors, tube thicknesses meeting TEMA/equal requirements, increased condensing area for load fluctuations and faster pull-down operations

• Evaporative condenser having coil bundle in SS 304 / SS 304L, SS 316/SS316L tubes (mainly for Ammonia refrigerant)

  • Evaporator (Chiller) shell & tube: Flooded, DX type With Highly efficient high heat transfer tubes in copper (for refrigerant other than Ammonia) for low refrigerant charge.
  • With Carbon steel, SS 304/SS 316 (Optional on request)
• Plate type heat exchangers (PHE) with SS 316 plates of reputed internationally known makes for low refrigerant charge
• Skid and equipment duly sandblasted and painted
• Totally Factory built self-contained, compact skid mounted ready to commission
• Customized design and development e.g. Two stage, Dual temperature operation, Hazardous area classification with Flame-Proof / intrinsically safe components for Electricals and Instruments, junction boxes, control/signal cables
• Reputed PLC / Microcontroller based user friendly control panel, necessary safety interlocks and auto manual operation of the chiller capable of handling load fluctuations for efficient operations. Provision for communication with DCS/SCADA, Data logger
• Compressor drive motor starter panels: Star-Delta, Soft starter, VFD with reputed switch-gears makes, VFD with Star Delta / Soft starter by-pass to eliminate the downtime of the system.
• Instruments & controls of reputed makes as per Industry standards
• Optionally Chilled water / Chilled Brine circuit will be offered with hot well & cold well with primary/secondary brine/water piping, primary pumps, accessories & Instrument and Controls
